• Ultra-High 430 W Output
• VBG Wavelength Locking (976 ± 1 nm)
• Integrated 30 dB Feedback Isolation
• 1020nm~1200nm feedback protection
• High-Brightness Output
• Rugged Industrial Package
• Fiber laser pumping
• Solid-state laser pumping
• Industrial Material Processing
• Scientific research
• Custom OEM Integration
| SPECIFICATIONS ( 25°C ) | SYMBOL | UNIT | K976BNZRN-430.0W | |||
|---|---|---|---|---|---|---|
| MINIMUM | TYPICAL | MAXIMUM | ||||
| OPTICAL DATA(1) | CW Output Power | Po | W | 430 | — | — |
| Center Wavelength | λc | nm | 976 ± 1 | |||
| Spectral Width (FWHM) | Δλ | nm | — | 0.7 | 1.0 | |
| Wavelength Shift / Temp | Δλ/ΔT | nm/°C | — | 0.02 | — | |
| Wavelength Shift / Current | Δλ/ΔI | nm/A | — | 0.03 | — | |
| ELECTRICAL DATA | Electrical-to-Optical Efficiency | PE | % | — | 48 | — |
| Threshold Current | Ith | A | — | 1.3 | — | |
| Operating Current | Iop | A | — | 25.0 | 26.0 | |
| Operating Voltage | Vop | V | — | 36.0 | 43.0 | |
| Slope Efficiency | η | W/A | — | 18.0 | — | |
| FIBER DATA | Core Diameter | Dcore | μm | — | 200 | — |
| Cladding Diameter | Dclad | μm | — | 220 | — | |
| Numeric Aperture | NA | — | — | 0.22 | — | |
| Fiber Length | Lf | m | — | 2 | — | |
| Fiber Loose Tubing Diameter | — | mm | — | 0.9 | — | |
| Minimum Bending Radius | — | mm | 88 | — | — | |
| FEEDBACK ISOLATION | Wavelength Range | — | nm | 1020 ~ 1200 | ||
| Isolation | — | dB | — | 30 | — | |
| OTHERS | ESD | Vesd | V | — | — | 500 |
| Storage Temperature(2) | Tst | °C | -20 | — | 70 | |
| Lead Soldering Temp | Tls | °C | — | — | 260 | |
| Lead Soldering Time | t | sec | — | — | 10 | |
| Operating Case Temp(3) | Ttop | °C | 20 | 25 | 30 | |
| Relative Humidity | RH | % | 15 | — | 75 | |
| Weight | W | g | — | 500 | — | |
